Cat6 Max Length for PoE: How Far Can You Run?

Cat6 PoE stops at 100m by spec. To go further, break the run with fiber, a second switch, or a wireless bridge.

Published 2026-08-27

Cat6 Max Length for PoE: How Far Can You Run?

PoE does not change the Cat6 distance rule — it is still 100 metres per cable segment, per TIA-568.

Why 100m, not "as far as it works"

Beyond 100m, both data timing and PoE voltage drop get risky. A 15W camera at the far end of a long run can arrive under-powered and reboot. Keep runs at or under 100m and you stay inside spec.

Three ways to go past 100m

Fiber + local PoE switch: run fiber to a remote PoE switch near the cameras, then Cat6 the last 100m to each one.
Second switch / midspan: place a switch at the 100m mark and start a fresh 100m segment. (A midspan injector alone does not extend distance — it still obeys the 100m rule.)
Wireless bridge: for job sites and open ground, a wireless bridge carries the signal kilometers without cable, then PoE the final drop.

Plan the pull

Buy Cat6 in a 305m box and measure each run before cutting. Keep a spare 10–15% on every length for risers and bends.

Frequently asked

Does PoE reduce the Cat6 100m limit?

No. PoE still follows the same 100m per-segment limit as data. Past 100m, voltage drop can starve the camera, so keep runs inside spec.

How do I run a camera more than 100m from the switch?

Break the distance: run fiber or a wireless bridge to a remote PoE switch near the cameras, then Cat6 the final 100m. A simple midspan injector alone will not extend the run.

Are SurveilForge accessories compatible with Hikvision, Dahua and Axis cameras?

Yes — they follow open surveillance standards (IEEE 802.3af/at PoE, RJ45, BNC, DC 12V/24V) and work with any brand using those standards, including Hikvision, Dahua and Axis. SurveilForge is an independent brand, not affiliated with any camera OEM.
